5 Axles Flatbed Semi Trailer
Product Details
Product Overview:
Our 5-axle flatbed semi trailer is the heavy-duty powerhouse of our fleet, specifically engineered for the most demanding transport tasks in Africa, the Middle East, and South America. With five high-capacity axles, this trailer offers superior weight distribution, ensuring compliance with strict road regulations while maximizing your payload up to 60-80 tons. It is the ultimate choice for transporting oversized machinery, steel coils, and heavy containers.
Specifications
Outside Dimension | 13000×2500×1550mm |
Loading Capacity | ≤80T |
Bottom Plate | 3mm diamond steel plate |
Twist Lock | 8/12 pieces |
Axle | 5 axles, 13T/16T per piece |
Tire | 12R22.5, 20 pieces |
Rim | 9.00-22.5, 20 pieces |
Suspension | Front 2 axles with air bag suspension; Rear 3 axles with mechanical suspension. |
Spring Leaf | 90(width)mm*13(thickness)mm*10 layers, 6pcs |
Support Leg | 28T heavy duty |
King Pin | 2.0 or 3.5 inch |
Valve | WABCO emergency valve |
Color and Logo | Customized |
Key Selling Points:
Unrivaled Load Capacity: Engineered with a reinforced "I" beam and high-tensile steel (Q345B/T700) to support payloads up to 80 tons without deformation.
Flexible Axle Configuration: First one or two axles can be equipped with air-lift systems to reduce tire wear and fuel consumption during empty returns.
Enhanced Stability: Five-axle synergy provides a larger contact area with the ground, significantly improving braking safety and stability on uneven road surfaces.
Heavy-Duty Components: Standard with 16T/20T heavy-duty axles and reinforced mechanical suspension to handle the toughest off-road conditions.
Why Partner With Us?
1. Direct Manufacturer: No middlemen, 100% factory direct price.
2. Overseas After-sales Support: We provide technical guidance to keep your fleet running.
3. Custom Engineering: We specialize in custom designs to match the specific road permit requirements of your country.
