4 Axles Cement Tanker Semi Trailer

Product Description:

Share:

Product Details


Product Overview:

Our 4 axle bulk cement tanker trailer is the ultimate heavy-hauling solution for construction and mining sectors in the Global South. With an additional axle for optimized weight distribution, it easily carries up to 60 tons of cement, fly ash, or lime powder. Designed with a high-strength V-shape tank and powered by a high-efficiency diesel engine/air compressor system, this tanker ensures rapid discharge and minimal residue on any terrain.


Specifications

Outside Dimension

10800×2500×3800mm

Total Volume

25m³-68m³

Tanker Body Material

5mm or 6mm/Q235 carbon steel

End Plate

5mm or 6mm/Q235 carbon steel

Diesel Engine

WEICHAI, Tianhe 4100/4102 or other brand

Compressor

BOHAI 10m³/12m³ or other brand

Axle

4 axles, 13T per piece

Tire

12R22.5, 16 pieces

Rim

9.00-22.5, 16 pieces

Suspension

All mechanical suspension; Or front axle with air bag suspension, rear 3 axles with mechanical suspension

Spring Leaf

90(width)mm*13(thickness)mm*10 layers

Support Leg

28T heavy duty

King Pin

2.0 or 3.5 inch

Valve

WABCO emergency valve

Color and Logo

Customized


Key Selling Points:

Superior Loading Capacity: The 4-axle design allows for a larger volume (up to 60cbm) while complying with strict road axle load regulations in South America and Africa.

Front Axle Lift (Optional): Equipped with an air-lift system on the first axle to reduce tire wear and fuel consumption during empty return trips.

High-Efficiency Discharge: Equipped with a 12m³/min or 14m³/min dual-cylinder air compressor and a powerful Weichai/Tianhe diesel engine for a discharge rate >1.2t/min.

Durable Tank Construction: Tank body made of 5mm-6mm high-tensile steel with automatic submerged arc welding to ensure maximum pressure safety and 0% leakage.

Minimal Residue Design: Optimized internal fluidized bed and 45° tank angle ensure a residual rate of less than 0.3%.


Why Partner With Us?

Factory Direct Pricing: Best competitive price directly from our own factory with strict quality control.

Custom Engineering: We specialize in adjusting tank thickness and axle spacing to meet your specific local transport laws.

Export Expertise: Rich experience in Ro-Ro and Bulk shipping to major ports in Africa, Middle East, and South America.
