2 Axles Carbon Steel Fuel Tanker Semi Trailer 20,000L - 30,000L Capacity

Product Description:

Share:

Product Details

Product Overview:

Our 2 axles carbon steel tanker semi trailer is the ideal solution for urban fuel distribution and medium-haul liquid transport. Specifically designed for markets with narrow roads or specific weight regulations in Southeast Asia and Africa, this compact tanker combines agility with a robust structure. Built with high-quality Q235B carbon steel and precision automatic welding, it ensures a long service life and zero leakage for gasoline, diesel, and industrial oils.


Specifications

Total Volume

20-30CBM

Tanker Body Material

5mm thickness carbon steel

End Plate

6mm thickness carbon steel

Compartment

3 compartments

Manhole Cover

Carbon steel API manhole cover, ∮500mm

Discharging Valve

Diameter is 3 inch

Discharging Pipe

4" rubber hose, 2 pcs, 6m/each

Main Beam

Welding design ,Q345 carbon steel

Axle

2 axles, 13T per piece

Tire

12R22.5, 8+1 pieces

Rim

9.00-22.5, 8+1 pieces

Suspension

Mechanical suspension (American Type)

Spring Leaf

90(width)mm*13(thickness)mm*10 layers, 4pcs

Support Leg

28T heavy duty

King Pin

2.0 or 3.5 inch

Valve

WABCO emergency valve

Painting

Complete chassis sand blasting to clean rust, 1 coat of anti-corrosive paint, 2 coats of final paint.

Color and logo are Customized


Key Selling Points:

Compact & Agile: The 2-axle configuration provides a smaller turning radius, making it perfect for urban gas station deliveries and navigating narrow construction sites.

Durable Carbon Steel Construction: 5mm-6mm premium Q235B steel ensures the tank can withstand high internal pressure and external impacts.

Optimized Payload Design: Lightweight but strong chassis design maximizes your payload per trip, effectively reducing fuel consumption.

Safe Discharge System: Equipped with professional emergency shut-off valves (bottom valves) and high-quality discharge valves to prevent spills and theft.

Rigorously Tested: Each tanker undergoes strict 24-hour pressure and leak detection tests to ensure 100% safety during transport.


Why Partner With Us?

Direct Factory Quote: Best value for money directly from our own workshop with strict quality control.

Regional Expertise: We understand the technical requirements and import standards for South America, Africa, and the Middle East.

After-Sales Reliability: Comprehensive warranty on the tank body and prompt spare parts supply.
