4 Axles Rear Dump Semi Trailer Factory Price for Africa with Electric Cover

Product Description:

Share:

Request Quote Now
Add to Quote List

Product Details

Product Overview:

Our 4 axles rear dump semi trailer with an integrated electric cover system is the ultimate solution for high-capacity, environmentally friendly bulk transportation. Designed for the toughest mining and construction sites in Africa and South America, the 4-axle configuration provides superior load distribution for payloads up to 80 tons. The remote-controlled electric cover system ensures cargo safety, prevents dust pollution, and significantly reduces loading/unloading time compared to manual covering.


Specifications

Outside Dimension

10200×2500×3600mm

Loading Capacity

50T-70T



Lifting Cylinder

HUBEI JIAHENG 202 complete hydraulic system

With some easy-going parts

With oil tanker and tubes

Working Box

High strength steel T700

Upper plate 14mm , middle plate 8mm , down plate 16mm

Main Beam

Bottom Plate Thickness: 6mm, Side Wall: 6mm; With Electric Cover.

Axle and Suspension

4 axles, 13T per piece


Rear 3 Axles with Mechanical Suspension; Front 1 Axle with Air Bag Suspension

Leaf spring

6pcs, 90*13*10mm

Wheel Tires and Rim

315/80R22.5-18 PR  16 +1 pcs


9.00-22.5   16 +1 pcs   Carbon Steel Rim

Landing Gear

Heavy duty 28 tons

King Pin

3.5 inch

Valve

WABCO emergency valve

Color and Logo

Customized


Key Selling Points:

Advanced Electric Cover System: Remote-controlled automatic cover saves labor and protects the environment by preventing cargo spillage and dust during transit.

Massive Payload with 4 Axles: The additional axle allows for higher legal payloads (50-70tons) and better stability on unpaved mining roads.

Reinforced High-Tensile Chassis: Main beams are made of Q345B/T700 high-strength steel with double-plate reinforcement to handle the extreme stress of heavy dumping.

Premium Hydraulic Lifting: Equipped with the world-renowned HYVA front-lifting hydraulic cylinder for smooth, powerful, and safe tipping performance.

Wear-Resistant Bucket: The dump body is constructed from NM450 or AR450 wear-resistant steel to withstand the impact of heavy rocks and abrasive minerals.


Why Partner With Us?

Direct Manufacturer Excellence: 20 years of expertise in exporting heavy-duty trailers to Africa, Middle East, and South America.

Smart Customization: We can integrate various types of electric covers (folding, sliding, or flip) based on your specific material and climate.

Professional Logistics: Expertise in Bulk and Ro-Ro lashing with anti-rust treatment for safe delivery to global ports.
